17.5 Kw Jar Blowing Machine , Stretch Blow Molding Machine For Plastic Bottles

Name: 175 Kw Jar Blowing Machine Stretch Blow Molding Machine For Plastic Bottles
Brand: Reliable
Price: 1 USD

Quality 17.5 Kw Jar Blowing Machine , Stretch Blow Molding Machine For Plastic Bottles for sale

Place of Origin : Jiangsu, China (Mainland)

Brand Name : Reliable

Model Number : RM-9B

Certification : CE ISO SGS

Supply Ability : 10 Set/Sets per Month for Semi Automatic PET Plastic Bottle / Barrel / Jar Blow Mouldi

Packaging Details : we use wooden case package outside, pe film package inside, or based on customer's requirement.

MOQ : 1 Set/Sets

Price : Negotiable

Payment Terms : L/C, T/T

Delivery Time : 25-35 working days

Blow Moulding Type : Stretch Blow Moulding

Voltage : 380V/3PH/50HZ

Power(W) : 17.5kw

Dimension(L*W*H) : 1750*670*1860mm

Weight : 600KG*2

Capacity : 100BPH

Contact Now

Semi Automatic PET Plastic Bottle Barrel Jar Blowing Mould Machine 100BPH

Description

1, Bottle Blow Moulding Machine is suitable for producing PET plastic containers and bottles. It is widely used to produce the carbonated bottle ,mineral water,carbonated drink bottle, pesticide bottle oil bottle cosmetics,wide-mouth bottle etc.

2.,Adopting double crank to adjust mould ,heavy locking mould, stable and fast ,Adopt infrared oven to heat the perform ,the perform rotated and heated equally.

3,The air system has been divided into two parts: pneumatic action part and bottle blow part to meet the different requirements for the action and blow .It can provide sufficient and steady high pressure for blowing large irregular shaped bottles.

4,The machine is also equipped with muffler and oiling system to lubricate the mechanical part of the machine.

5,The machine can be operated in the step-by-step mode and the semi-auto mode.

6,The machine is small with low investment, easy and safe to operate .

Function

1. Controlled by MITSUBISHI touch screen computer. Operate consistently and simply.

2. Pneumatic elements from FESTO (German) and SMC (Japan)

3. Energy-saving and environmentally friendly design. Mechanical units are compact and rational.

4. Malfunction alert and diagnostic units allow easy maintenance.

5. Suitable for manufacturing a variety of PET bottles: mineral water bottles, edible oil bottles, soda bottles, medicine bottle, cosmetics bottles etc..

6. Oven can be made according the different preform requirements of customers

Technical Data

Container	Product material	PET
	Volume	0.1L-2L
	Theoretical output	1200-1600PCS/H
	Preform length	15mm-350mm
	Preform inner diameter	φ5mm-38mm
Moulding	Max.mould plate Dimenstion(L x W)	350x380mm
	Max.mould thickness	180mm
	Clamping force	45KN
	Mould opening stroke	160mm
Machine size and weight	Main machine (L x W x H)	160x60x161KM
	Main machine weight	500Kg
	Heater (L x W x H)	187x63x145KM
	Heater weight	250Kg
	Power	17.5kw

Our Service

The sample service

1.we can send you the video of the running machine.
2.you are always welcome to come to visit our factory, and you may see the operation of the machines here . We will make the arrangement to pick you up when you come .
3.If we get the permission of the customer who has brought the machines from us ,we can tell you their contact information, you can go to visit their factory.

Customized service

1.we can design the machines according your requirements(material ,power,filling type,the kinds of the bottles, and so on).
2.at the same time we will give you our professional suggestion .

After-sales service

1.we will provide the bill of load on time to make sure you can get the machine quickly
2.when you finish the Preparation conditions ,our engineer will go to your factory for the installation, testing and also training .
3.we provide one year warranty with spare parts free.

FAQ

Q1:Are you a trading company or a manufactory?
A1:We are a manufactory,can give u best service .
Q2:What’s your guarantee or the warranty of the quality if we buy your machines?
A2:We offer you high quality machines with 1 years guarantee . we will give u spare part free in 1 years
Q3:When can I get my machine after I paid
A3:We will deliver the machines on time as the date we agreed both side.
Q4:How can I install my machine when it arrives?
A4:We will send our engineer to your side as soon as you get all your machines ready , for testing and teaching your technicians how to run the machines.
Q5:How about the spare parts?
A5:After we deal down all the things , we will offer you a spare parts list for your reference.
17.5 Kw Jar Blowing Machine , Stretch Blow Molding Machine For Plastic Bottles
